nomex insulation paper NMN
Thickness: 0.15, 0.20, 0.25, 0.30, 0.35, 0.40, 0.45mm
Width: 10-914mm
Features and Applications nomex insulation paper NMN
:
NMN-Nomex paper/polyester film composite material belongs to Class F (155 degree).
Excellent heat resistance, dielectric property and mechanical strength.
As slot, interturn and liner insulation for F-grade motors and electric appliances
NMN has good cutting and overload resistance, high stiffness. Good compatibility with insulation varnish.
Availability nomex insulation paper NMN :
NMN Form: roll, sheet, strip
Three layers: both of outside are Nomex paper, middle is polyester film
Properties:
Bond strength at (130±2)degree, 10min: no delimitation.
Breakdown voltage (no bending)≥: no delimitation., no blister, no adhesive flow
Technology Data nomex insulation paper NMN
NO. | Item | unit | Normal value | result | ||
1 | Normal Thickness | mm | 0. 20 | 0.21mm | ||
2 | Weight | g/m2 | 285 ± 25 | 292g | ||
3 | Tensile Stength | MD | no bending | N/10mm | ≥ 260 | 266 |
after bending | ≥ 185 | 183 | ||||
TD | no bending | ≥ 185 | 186 | |||
after bending | ≥ 150 | 155 | ||||
4 | Elongation | MD no bending | % | ≥ 10 | 10.7 | |
TD after bending | ≥ 15 | 15.5 | ||||
5 | Breakdown voltage | no bending | KV | ≥ 12 | 13.2 | |
after bending | ≥ 10 | 10.5 | ||||
6 | Bonding strength at room temperature | / | No delamination | Qualified | ||
7 | Heat resistance index | / | 155 ℃ | 162 ℃ | ||
